The j5create JTD562 8K Thunderbolt 4 Docking Station is built around an Intel Thunderbolt 4 chip and an aluminium enclosure with rubber end caps. Three downstream Thunderbolt 4 ports at 40Gbps handle displays, storage and daisy-chained devices; a single monitor can run up to 8K@60Hz with DSC, or two monitors at 4K@60Hz. Three 10Gbps USB-A ports, a USB 2.0 fast-charge port, a UHS-II SD 4.0 reader, Gigabit Ethernet and an audio jack cover the rest of the desk. The included 135W adapter lets the dock charge the laptop at up to 96W, and two USB-C to DisplayPort cables are in the box.
Key features
- Three Thunderbolt 4 downstream ports at 40Gbps with daisy-chain support
- Single display up to 8K@60Hz (DSC) or 4K@144Hz (DSC); dual displays at 4K@60Hz
- 96W Power Delivery to the laptop from the included 135W adapter
- Three USB 3.2 Gen 2 Type-A ports at 10Gbps and one USB 2.0 BC1.2 charging port
- SD 4.0 UHS-II reader (312MB/s), Gigabit Ethernet, 3.5mm combo audio
- Anti-theft security slot; for Thunderbolt 4 Mac and Windows laptops
Specifications
| Host connection | Thunderbolt 4 (backward compatible with Thunderbolt 3) |
|---|---|
| Total ports | 11 |
| Display outputs | 3x Thunderbolt 4 (up to 2 displays) |
| Max resolution | 8K@60Hz with DSC (single display) |
| Power Delivery | 96W |
| Ethernet | Gigabit |
| Dimensions | 7.64 x 3.32 x 1.21 in |
| Weight | 14.5 oz |
In the box
- JTD562 Thunderbolt 4 Docking Station
- 135W AC adapter (up to 96W PD charge)
- Thunderbolt 4 cable, 2.3 ft/70 cm
- 2x USB-C to 4K DisplayPort cable (JCA141)
- Quick installation guide
